Page 15
— 10 —
2. EXPLANATION OF PRINTER PARTS
2.1 Printer Appearance
POWER LED
ERROR LED
FEED switch
Power
connector
Rear Connectors
Paper Cover Inside
Operation Panel
Interface connector
(Serial, parallel, etc.)
Paper feed roller
Paper cutter
Print (thermal)
head
Paper-near-end
sensor
Paper-end sensor
Paper cover
Power switch
Operation panel
Cover open button
