Control Menu

Set interval time from 15 to 360 seconds

Set duration time from 1 to 5 seconds

Set DMX address from 1 to 512

Turn On/Off W-DMX

Rest W-DMX connection

Turn On/Off wireless control

Turn On/Off to have a quick start (to run last settings)

DMX Operation

Making the DMX Connection

– Connect machine to a DMX controller or to one of the

machines in the DMX chain.

DMX Connector Pin Assignment

The machine provide 3 or 5 pin XLR connector for DMX connection. Diagram below indicate

pin assignment information

Interval Set

15 Sec

Duration Set

5 Sec

Wireless

Off

Quick Start

Off

DMX512

Add: 1

W-DMX Power

Off

W-DMX Reset

Off
