9
DMX Channel Function
Channel Mode Channel Value Function
2
1
0-4 Faze off
5-255 Faze 1-100%
2
0-4 Fan 20%
5-255 Fan 21-100%
1 1
0-4 Faze off
Fan 100%
5-255 Faze 1-100%
Fan 100%
Sync 1
0-4 Faze Off
Fan 20%
5-255 Faze 1-100%
Fan 21-100%
Status of W-DMX connection (Optional)
Symbol on the Liquid Crystal Display Status of W-DMX connection
●
Transmitter assigned, DMX signal received
◎
Transmitter assigned, No DMX signal
⊙
Transmitter link lost or linking to transmitter
○
Transmitter not assigned
Wireless Remote Control Operation (Optional)
The optional wireless remote control system consists of a transmitter and a receiver on the
rear of the machine.
