5
Product Overview
Setting Up
Step 1: Place the machine on a flat surface and in a suitable large area with at least 50 cm
open space around the machine.
Step 2: Fill the fluid tank with Antari approved fluid.
Step 3: Connect the machine to suitable rated power supply.To determine the power
requirement for the machine refer to the label on the back of the machine.
Always connect the machine to a protected circuit and ensure it is properly
grounded to avoid risk of electrocution.
Step 4: Turn on the machine and allow it to heat up. Heat up takes approximatly 4 mintues.
Once the machine has reached operating temperature, the display will show Ready to Faze.
Now the machine is ready for operation.
Blue LCD screen, Timer
mode, Volume mode
Neutrik PowerCon
Breaker
XLR 3-Pin DMX Connector
WDMX Wireless Solution
XLR 5-Pin DMX Connector
Power ON / OFF
