9
DMX Settings for Antari ICE Low Fog Machines with onboard DMX
6 – 249 = Volume Control ( 5% - 95%)
250
– 255 = Maximum Volume Output ( 100%)
The ICE Low Fog Machine has onboard DMX control. Currently this model uses 1
channel to
control Volume output operation. Each channel has a value range of 0 to 255.
If Channel A has a value from 0 to 5, the unit is OFF.
Between the values 6 to 249 the volume of fog output is regulated. With 6 being the
inimum volume of fog produced and 249 approaching the maximum. The volume output
rises as the DMX value is increased.
If Channel A has a value from 250 to 255, the machine will operate at maximum
output.
Note: In the example above, if the machine were assigned the DMX address of 124,
Channel A would correspond to DMX address 124.
In general, Antari fog machines with onboard DMX conform to the following performance
specifications:
1. Average Operating temperature = 250oC
2. Fogger can maintain maximum output for 30 seconds or more
3. Fogger can maintain constant output at 30% volume setting
(roughly a value of 70 – 75).
Antari Onboard DMX Fog Machine Settings
Off
