9
Fuse
100V = T6.3A 250V
110
– 120V = T7A 250V
220
– 240V = T4A 250V
Status Messages
Status LED Indication
Flashing Green Machine is heating up
Flashing Green (3 seconds) Self Cleaning
Solid Green Machine ready for operation
Flashing Amber Producing haze
Solid Amber DMX signal received
Solid Red Heater is overheating, machine can
not be operated
Flashing Red Liquid detected backflow to air pump
Flashing Red/Green Machine cannot heat up
Technical Specifications
Input voltage 110-120V 60Hz
220-240V 50Hz
Fuse 100V = T6.3A 250V
110
– 120V = T7A 250V
220
– 240V = T4A 250V
Heater 100Vac - 520W , 120Vac
– 800W
220Vac - 600W , 240Vac
– 730W
Warm-up time 3.5
– 4 min. (approx.)
Coverage volume 3000 cu.ft./min. (85 m³/min.)
Max. operating time 7.2 hrs max. output
Fluid tank capacity 1.3 l (0.34 gal)
Fluid consumption 3 ml/min.
