SCHEMATIC PARTS LIST
Ref # Item # Description
1 972-101 Center Pole Screw and Washer (1)
2 972-080 Base
3 972-106 Casters (5)
3A 972-106-1 Single Caster
4 972-107 Outer Pole
5 972-108 Knob
6 972-109 Spring
6A 972-107A Gasket
7 972-110 Inner Pole
8 972-111 Tightening Device
9 972-112 Basket
9A 752-113 Bracket
9B 752-114 Manometer Mounting Hardware
9C 752-115 Manometer Bracket Hardware
ROD & BASE ASSEMBLY FOR 752M
9B
4
5
6
7
8
9
9A
9C
9C
6A
1
2
3
3A
