3. Setup
9 12/28/2009 12:38 PM
Fixture Mounting
Location
Mounting
Brackets (2)
Mounting
Orientation
The Satellite™ D-Fi may be mounted in an upright, safe position, provided there is adequate room for
ventilation.
Rigging
Be sure that the structure can support the weight of the fixture. Please see the “Technical
Specifications” section of this manual for a detailed weight listing. Mount the fixture securely. This
may be done with a screw, nut and bolt, or a hanging clamp. The hole in each mounting bracket is 13
mm in size. When rigging, consider routine maintenance and control panel access. Please see the
following steps for installation.
Due to the internal battery in the product, this product may not be operated in a position
other than upright.
Safety cables must always be used.
2 clamps, one on either mounting bracket, must be used if operating this fixture is any
position other than floor standing.
