1.3.3 Particulate Filters: The standard particulate prefilter will
be AAF PolyKlean Blue pads. Depending on the size of the
PORTA-Scrubber ordered, a round 24˝ diameter x 2˝ deep or a
round 37˝ diameter x 2˝ deep may be supplied. PolyKlean Blue
2˝ deep filters are individually packaged.
Note that other optional or special filter arrangements may
be supplied depending on the requirements of the project.
Check the purchase order and the AAF submittal drawing(s)
for details.
1.4 Product Model Designations
The PORTA-Scrubber model is designated as follows:
• Pressure losses across the filter system at nominal airflow
design velocities
• Product details
If you are unable to locate the appropriate drawing, please
contact customer service at 888.223.2003 to obtain a copy.
1.6 Assembly – General Comments
As indicated previously, the individual components that will
comprise the filtration system may ship separately and will be
required to be installed on site. The SAAF PORTA-Scrubber is
a self-contained product and, consequently, a minimum
amount of assembly is required. Refer to section 3.0, Installation
Instructions, of this manual for further detailed instructions.
Consult with an experienced installer to obtain an accurate
estimate of the time, personnel, and equipment resources and
tools that will be required to complete the assembly and
installation of the filter system. Site assembly will be limited to
moving and lifting individual components, screwing components
together, and caulking. The PORTA-Scrubber weights and
dimensions can be found on the product drawings. Packages
of the chemical media will typically have a maximum weight of
approximately 50 pounds (23kg). Particulate filters will typically
weigh less than the chemical media filters.
Completion of the following preparations and provision of the
following items will be the responsibility of the installer or others:
• Site preparation
• Connecting hardware for attaching inlet and outlet ducts
• Caulk, as required
• Inlet and outlet ducts, or other sheet metal parts, as required
These items will not be supplied by AAF unless noted specifically
in the AAF quotation and in the accepted customer purchase
order. In general, assembly of the filter system will consist of
the following:
• Preparation of the installation location
• Transportation of all components to the installation location
• Unpacking the PORTA-Scrubber
• Installing the PORTA-Scrubber
• Installing inlet and outlet ducts
• Unpacking particulate filters
• Installing particulate filters
• Unpacking chemical media
• Installing chemical media
• Cleaning the site
• Start-up and commissioning of the filter system
1.7 Related System Equipment
Ventilation systems can include other equipment including but not
limited to:
• Fan(s), if not supplied as part of the PORTA-Scrubber
• Dampers
• Analog instrumentation
• Electronic instrumentation and controls
Neither the interface of these items with the filtration system
supplied by AAF, nor the installation, operation, and maintenance
of these items is covered in this manual. Whether these items are
supplied by AAF or by others, consult the documentation specific
to these products for appropriate instructions.
This list by no means exhausts the possibilities and the system
provided may be different from those shown here. Consult
the AAF drawing that was supplied on the purchase order
in question.
1.5 Product Drawings
Details of standard PORTA-Scrubber systems are shown on the
following AAF drawings:
Model AAF
Drawing Number
PS-200 123B-3052941-D
PS-200NP 123B-3040821-F
PS-500 123B-3040789-F
PS-500NP 123B-3040839-F
Copies of the appropriate drawings should have been supplied
as part of the AAF submittals in response to the purchase order.
Obtain and review the drawing(s) before proceeding with the
installation of the filtration system. The PORTA-Scrubber
drawings include the following details:
• Overall filter system dimensions
• Shipping weights
• Operating weights
• Sizes and quantities of the particulate and gas-phase
filters required
• Details of the gas-phase chemical media supplied
• Details of the particulate filters supplied
• System design airflow
Table 1: Examples of Typical PORTA-Scrubber Sizes
Size designation Height (in.) Diameter (in.) Inlet Size (in.)
PS-200 51¼ 22¼ 4˝
PS-500 64¾ 35½ 6˝
PS-200NP
Denotes Non-Powered
unit (Powered units will
not have any designation)
Nominal airflow in
cubic feet per
minute (CFM)
Equipment
Type
