9
ENGLISH
Using the Detachable Front Panel
• To Detach the Front Panel
1. Press the OPEN button, then the
front panel will be folded down.
2. Remove the front panel by pulling its
middle-hand side outward.
3. For safekeeping, store the front panel
in the supplied protective case
immediately after being removed.
4. Push the front metal plate into the
main body. A ‘click’ sound will be
heard.
• To Re-install the Front
Panel
1. Push the front panel into the main
body. A ‘click’ sound should be heard.
2. Note that if the front panel fails to
lock in position properly, control
buttons may not function and the
LCD display may not light some
segments. In this case, press the
OPEN button and then re-install the
front panel again.
• Precautions During
Handling
1. Do not drop the front panel.
2. Do not put pressure on the display or
control buttons when detaching or re-
installing the front panel.
3. Do not touch the contacts on the front
panel or on the main unit body. It may
result in poor electrical contact.
4. If dirt or foreign substances adhere to
the contacts, this can be removed
with a clean and dry cloth.
5. Do not expose the front panel to high
temperatures or direct sunlight.
6. Prevent any volatile agents (e.g.
benzene, thinner, or insecticides)
from touching the surface of the front
panel.
7. Do not attempt to disassemble the
front panel.
PROTECTIVE CASE
FRONT PANEL
OPEN
