Section 1 Introduction
Enviro™ Bench Scales are stand-alone scale bases that may be used with any compatible Hardy
Instruments Weighing Controller / indicator, including the Hardy Enviro™ Series Checkweigher.
They are constructed of stainless steel and are designed to be used in a rugged and sanitary check
weighing application. The load cells are made from either aluminum or stainless steel. This
manual contains information on all Enviro™ bases to date.
Hardy Instruments appreciates your business. Should you not understand any information in this
manual or experience any problem with the product, contact our Customer Service Department at:
Phone: (858) 278-2900
FAX: (858) 278-6700
Web Site: www.hardyinst.com
Support e-mail address: [email protected]
Assembly:
1. The Bench Scale is shipped fully assembled. Inspect the packing and the Bench Scale for
shipping damage, be sure to remove any packing material from the Bench Scale.
Note: The load cell cable is shipped with the ends of the wires "tinned." DO NOT
lengthen or shorten the load cell cable as this may void any warranties.
2. Wire the load cell cable to the indicator per the following wire lists.
All Bench Scales
Function Wire Color Function Wire Color
Excitation (-)
Excitation (+)
Sense (+)
Sense (-) Black
Green
−
− N/C ---
Shield
Output (+)
Output (-) −
Shield
White
Red
Section 2 Enviro™ Bench Scale Model Numbers
Drawing # Description
Sales Model
Numbers to Order
Capacity
(lb)
30290 Scale Assy, Hardy 10x10-2# with pillar and Instrument HICWSB1010-0002 2
30291 Scale Assy, Hardy 10x10-6# with pillar and Instrument HICWSB1010-0006 6
30292 Scale Assy, Hardy 10x10-10# with pillar and Instrument HICWSB1010-0010 10
30293 Scale Assy, Hardy 10x10-25# with pillar and Instrument HICWSB1010-0025 25
30294 Scale Assy, Hardy 12x12-30# with pillar and Instrument HICWSB1212-0030 30
30295 Scale Assy, Hardy 12x12-50# with pillar and Instrument HICWSB1212-0050 50
30296 Scale Assy, Hardy 18x18-50# with pillar and Instrument HICWSB1818-0050 50
30297 Scale Assy, Hardy 18x18-100# with pillar and Instrument HICWSB1818-0100 100
30274 PLATFORM ASSY, HARDY 10x10 - 2# CAP HIWDPS1010-0002 2
30275 PLATFORM ASSY, HARDY 10x10 - 6# CAP HIWDPS1010-0006 6
30276 PLATFORM ASSY, HARDY 10x10 - 10# CAP HIWDPS1010-0010 10
12/09 1 0596-0316-01 Rev B
