42 Hangar 9 Alpha 40 ARF Assembly Manual
optional: gluing the Wing halves
Required Parts
Wing panel (left and right) Aluminum wing tube
Covering (white) Covering (red)
Required Tools and Adhesives
30-minute epoxy Mixing cup
Mixing stick Epoxy brush
Rubbing alcohol Paper towel
Low-tack tape Covering iron
Note : It is not necessary to glue the wing panels
together on your model. This section has been provided
in case you opt to do so. Make sure your vehicle has
enough room to transport the joined wing before joining
the wing panels using this method.
 Step 1
Locate the items necessary to join the left and
right wing panels.
 Step 2
Slide the wing tube into the wing panel as shown. The wing
tube will only slide in halfway, so do not force it in any
further than it will slide easily.
 Step 3
Mix 1/2-ounce total (15ML) of 30-minute epoxy. Use an
epoxy brush to apply a thin layer of epoxy to each of the
wing roots as shown.

Step 4
Slide the remaining wing panel onto the wing tube.
