30 Hangar 9 Alpha 40 ARF Assembly Manual
 Step 5
Once set, use pliers to make a 90-degree bend in the
pushrod wire at the mark made.

Step 6
Use a pin vise and 5/64-inch (2mm) drill bit to enlarge the
hole in the servo horn that has aligned for use with your
linkage position.
 Step 7
Remove the servo horn from the servo using a #1 Phillips
screwdriver. Use diagonal cutters to remove any unused
arms from the horn so they don’t interfere with the operation
of the servo.
 Step 8
Slide the pushrod wire through the hole in the servo horn.
The horn will fit against the bend in the wire.
 Step 9
Slide the pushrod snap link on the wire. Rotate the link so it
snaps on the wire. You may need to use pliers to snap the
link onto the wire.
