Table Of Contents
Safety instructions 2
Congratulations / Unpacking 3
Who’s Who 4
Sensors & new ways of expression 5
I. Register and Install
Download and install the editor / Download the manual
7
II Connections
II.1 Step 1: Connect a sensor to Eobody2
8
II. 2 Step 2: Connection to your computer/II.2.Connect 2 or more Eobody2 to your computer 9
II.3. How is the unit powered? USB powering/External powering/How do I know that I need an
external powering?/ activity LED
10
III. Eobody2 editor
III.1. Global parameters window/Open the editor
III.2. Eobody2 and your computer/Select Eobody2 MIDI port /your eobody name /
save to file / load to file
11
III.3. Eobody2 internal memory configuration/
check current parameters/save current parameters/init all parameters/revert to save/
all off/delay/change name/check name/print incoming messages
12
III. 4. Internal process & editor parameters 13
III.5. Parameters window
Open the Parameters window/What are these internal processing parameters?
14
status / analogue zoom/digital zoom and offset 15
inverse / filter / gate 16
Note on message/low/hi 17
Formating messages to host
Type / CC Control Change / Program Change message PC / Pitch Bend PB /
Monophonic Aftertouch Atm
18
message Channel: [1-8] / value val: 0 – 127 Configuration map for analogue inputs 19
IV. Making my own sensors
Making my own sensor switch/Making my own sensor potentiometer/
Making my own sensor with other kinds of sensors
20
Amplification / TRS 1/4’’ jack 6,35 mm connectors 21
V. List of MIDI Controllers 22
VI. MIDI Implementation 23
VII. Technical specifications 24
USB 8 sensor interface / Table Of Contents
