1. BNC Video Out
The SL-DVR is an economic and camera DVR with all-in-one audio, video and playback function.
It has a SD memory card slot in the camera.
It is simple to operate and is suitable for all evidence gathering needs (such as
on-site video evidence, loss prevention, babysitting surveillance).
2. RCA Audio Out
3. OSD Menu Button
4. Audio and Video Out
5. DC12V Power Input Terminal Block
6. Power Indicator
7. SD Card Slot
3
4. SL-DVR Description
4.1 About the SL-DVR
4.2 SL-DVR Layout
4
PL
DC 12V
-
+
Video / Audio
POWER
VIDEO OUT
AUDIO OUT
1
7
2
3
4
5
6
