DVR User Manual
23
4.3 Record Configuration
Record configuration includes six sub menus: enable, record bit rate, time, recycle record, stamp and snap.
4.3.1 Enable
Step1: Enter into MenuSetupRecordEnable tab. Refer to Fig 4-9:
Fig 4-9 Record Configuration-Enable
Step2: Checkmark record and audio.
Step3: Select All to setup the same settings for all channels.
4.3.2 Record Bitrate
Step1: Enter into MenuSetupRecordRecord Bitrate tab. Refer to Fig 4-9:
Step2: Setup rate, resolution, quality, encode and max bit stream
Step3: Select “All” to set same settings for all channels.
Step4: Click “Default” button to restore default setting; click “Apply” button to save the setting; click “Exit” button to exit the current
interface.
Parameter Meaning
Record
To enable/disable recording for
the channel
Audio
To enable/disable audio recording
for the channel
