COP-USA CHLP100IR-EF - Manual (Page 3)

3. AE
LENS SELECT DC ELC
BRIGHTNESS 0~60 0~60
BACKLIGHT OFF / LOW / MID / HIGH OFF / LOW / MID / HIGH
FLICKERNESS ON/OFF NOT USE
SHUTTER SPD. NORMAL, 1/25~1/10000 NOT USE
AGC MAX SET AGC OFF / LOW / MID / HIGH AGC OFF / LOW / MID / HIGH
MAX FLD SET OFF/2FLD/4FLD/8FLD/16FLD/32FLD/64FLD OFF/2FLD/4FLD/8FLD/16FLD/32FLD/64FLD
INITIAL
LENS SELECT
DC‐ License plate camera mode
ELECTR‐Uses an electronic iris
BRIGHTNESS
This option allows you to set the brightness of the
camera video
BACKLIGHT
What this will do is brighten the object up in the
SHUTTER SPD
Adjusts the Shutter Speed (Normal, 1/25~1/10000)
AGC MAX SET
Automatic Gain Control can be set to LOW, MEDIUM,
HIGH or OFF. In a dark environment, when AGC is set
to High, the image becomes brighter. The setting here is
related to the setting in Day & Night mode.
MAX FLD SET
4. D&N
D/N MODE EXT AUTO DAY NIGHT
EXT INPUT LOW/HI COLOR NOT USE NOT USE NOT USE
LUX SET NOT USE LOW/MID HIGH NOT USE NOT USE
FILTER DLY NOT USE 0~10 SEC NOT USE NOT USE
BURST ON/OFF ON/OFF ON/OFF ON/OFF
INITIAL ON/OFF ON/OFF ON/OFF ON/OFF
RETURN
foreground and dim everything down in the
background allowing you to see the
object better in the foreground
FLICKERNESS
Select this mode if flickering occurs on the screen,
because of an irregular balance
between illumination and scan frequency The shutter
D/N MODE
This Option allows you to mirror the image horizontally , vertically and
Rotate (turns the image Upside down.
EXT INPUT
Adjust the Image Sharpness decreasing or Increasing the Values
LUX SET
This Option allows you to mirror the image horizontally , vertically and
Rotate (turns the image Upside down.
Slow shutter have many estate：OFF 2/FLD 4/FLD 8/FLD
16/FLD32/FLD 64/FLD
