4 Description of function
19 B-811 Operation Manual, Version G
4 .2 Overview of the instrument
1
2
3
4
5
6
7
a Operating panel
b Protective shield
c Main power switch
d Heating element e Beakers
f Extraction chamber
g Condenser
Fig. 4.1: Overview of the instrument
5
1
3
4
2
7
6
a Condenser
b Glass sample tube
c Upper heating element
d Solvent beaker
e Glass valve
f Lower heating element
g Optical sensor
Fig. 4.2: Overview of a single extraction position
