6 Operation
23
K-439 Operation Manual, Version A
6 .1 .2
System rear side
T 10A L 250 V
Bracket with magnetic
(elbow) suction plugs
T-piece with
suction hoses
Type plate
Fuse type:
Fuse holders
Power socket
Mains socket for
Scrubber connection
To access the glass fuses on the rear side use a slotted screwdriver.
•
➥ Slightly push in the slotted insert and turn it approx. a quarter-turn counterclockwise.
➥ Release the pressure off the insert — it will pop out by weak spring force.
