Fitting the TV Bracket
Colocación del soporte de TV

C

x1

D

x1

E

x2

F

x2

K

x2

5mm

C

F

K

K

F

V

E

E

D

!

Up

Arriba

V

IMPORTANT!

It is essential you fit fixing

plate V the correct way up

IMPORTANTE!

Es imprescindible instalar la

placa de fijación V orientada

correctamente hacia arriba
