AVF Group YML2500: ANY WALL TV Mount - Manual (Page 6)

8 Hanging The TV
Push the yellow Hangers (on the back of the TV) in to the yellow
receptor on the Wall Brackets. Slide down into place. Ensure both
yellow Hangers are fully engaged. If cables from the TV prevent
the TV resting against the wall then an alternative fixing
configuration will be required (See Section 9).
P
A
B
Slide the pull cord handles up
the cord so they are behind the
TV (still accessible but not visible
from the front of the TV). Tie a
knot in the cord and cut off the
excess.
Removing the TV:-
This is a two person job. To remove the TV, one person
should pull both Pull Cords while another lifts the TV.
Use the 3mm hex key
(P) to fine adjust the
level of the TV once
fitted to the wall.
TV must be parallel
to wall. Use spacers /
stand-offs as shown.
