AVF Group YML2500: ANY WALL TV Mount - Manual (Page 5)

7 Install Wall Fixings
Use the correct fixings for your wall type. Mixing fixing types may be required for installations that
span different wall types. DO NOT OVER TIGHTEN SCREWS.
Ø10mm
(25/64")
Remove
dust from hole
Ø18mm
(3/4")
J L M K H I G A O P
Solid W
all
Dot & Dab
Plasterboard
/ Sheetrock
W
ood Stud
Metal Stud
75mm (3")
108mm (4-1/4")
Ø10mm
(25/64")
Remove
dust from hole
40mm Max
(1-9/16")
O
If gap is above 40mm (1-9/16") use
Plasterboard / Sheetrock fixing method
Ø3mm
(1/8")
Use Plasterboard
/ Sheetrock fixings
Ø3.5mm
(9/64")
Use Plasterboard
/ Sheetrock fixings
Only one fixing will be in the wood stud. The other fixings will be in plasterboard / sheetrock (see above).
Only one fixing will be in the metal stud. The other fixings will be in plasterboard / sheetrock (see above).
H
L
P
Lubricate screw
thread with soap
A M
Lubricate screw
thread with soap
A J
A
I
Lubricate screw
thread with soap
Hand tighten
only
*
*
Turn until secure
Do Not over
tighten
40mm (1-9/16") Min gap
A
M
Use Plasterboard
/Sheetrock fixings
A
K
Use Plasterboard
/Sheetrock fixings
G
