AW58100HTA, HTS User’s Manual
PAGE 2 Technical Support (650) 384-0000 www.avalanwireless.com
© by AvaLAN Wireless Systems Inc. All rights reserved.
Revision 6.26.2014
125A Castle Drive
Madison, AL 35758
Phone: (650) 384-0000
Fax: (650) 249-3591
The AW58100HTA is a radio with dual omnidirectional antennas. It serves as an Access Point (master) in
a point-to-multipoint network. The AW58100HTS is a radio with a dual flat panel high gain directional
antenna. Multiple AW58100HTS radios can serve as a Subscriber Units (clients) in conjunction with an
AW58100HTA.
The AW58100HTA includes: The AW58100HTS includes:
(1) AW58100HTA Access Point Radio
(1) Heavy Duty Pole-mount Bracket
(1) Power Over Ethernet Injector
(1) 18 VDC power supply
(1) AW58100HTS Subscriber Unit Radio
(1) Heavy Duty Pole-mount Bracket
(1) Power Over Ethernet Injector
(1) 18 VDC power supply
Table of Contents
Quick Start Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
LED Status Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Digital Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connecting To The Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Changing the Configuration - Step By Step . . . . . . . . . . . . . . . 6
Viewing Status Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Physical Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Frequency Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Warranty and FCC Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
If you have any questions when configuring your AvaLAN system, the best place to get answers is
to visit www.avalanwireless.com. You will also find the latest updates there. If more assistance is
needed, send email to [email protected].
To speak to a live technician, please call technical support at the number below during normal
business hours.
