AW58100HTP-PAIR User’s Manual
PAGE 2 Technical Support (650) 384-0000 www.avalanwireless.com
© by AvaLAN Wireless Systems Inc. All rights reserved.
Revision 6.26.2014
125A Castle Drive
Madison, AL 35758
Phone: (650) 384-0000
Fax: (650) 249-3591
The AW58100HTP-PAIR consists of two AW58100HTS radios preconfigured with a dual flat panel high
gain directional antenna.
The AW58100HTP-PAIR includes:
(2) AW58100HTS Bridge Radios
(2) Heavy Duty Pole-mount Bracket
(2) Power Over Ethernet Injector
(2) 18 VDC Power Supplies
Table of Contents
Quick Start Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
LED Status Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Digital Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connecting To The Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Changing the Configuration - Step By Step . . . . . . . . . . . . . . . 6
Viewing Status Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Physical Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Frequency Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Warranty and FCC Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
If you have any questions when configuring your AvaLAN system, the best place to get answers is
to visit www.avalanwireless.com. You will also find the latest updates there. If more assistance is
needed, send email to [email protected].
To speak to a live technician, please call technical support at the number below during normal
business hours.
