INPUTs
High Input Impedance - 3.9M ohms Input range 150mv to 20v p - p
Low Input Impedance - 10k ohms Input range 300mv to 40v p - p
Effects Return Impedance - 22k ohms Input level 0dbu nominal
OUTPUTs
Tuner Output Impedance - 10k ohms Level 0dbu nominal
Effects send Impedance - 22k ohms Level 0dbu nominal
d.I.Output 600 ohms balanced Level -20dbu nominal
speaker Outputs Minimum Impedance - 4 ohms
Frequency Response -3db at 22hz and 25khz
EQUALIsATION
Bass +/- 15db @ 100hz
Lo Mid +/- 15db @ 340hz
Middle +/- 15db @ 660hz
Hi Mid +/- 15db @ 1.6khz
Treble +/- 15db @ 7khz shelving
signal to Noise Better than 80db (E.Q. Flat)
distortion Less than 0.5% THd
Output Power 100watts RMs into 4 ohms.
