3
I
NTRODUCTION
The Bridge5-24 is a IEEE 802.11an ISM band 5GHz wireless outdoor Bridge, which
support data rates up to 150Mbps. It is rain and splash proof when install in upright
position. Bridge5-24 also integrated 23dBi high-gain 5GHz patch antenna and
passive PoE for simplify use and installation.
H ARDWARE D ESCRIPTION
Below are Bridge5-24 hardware descriptions
①
②
①
High-Gain 23dBi 5GHz Panel Antenna
②
PoE LAN Port ( Passive 24V PoE )
