AWAP411 150M Wireless 11N Access Point
6) Bridge with AP: This mode can bridge the AP and up to 4 APs also in bridge mode to
connect two or more wired LANs.
Figure 4-12 Wireless Settings in Repeater mode
¾
SSID (Set Service Identifier) - Identifies your wireless network name. Create a name up to 32
characters and make sure all wireless points in the wireless network with the same SSID. The
default SSID is AWAP411. This value is case-sensitive. For example, TEST is NOT the same
as test.
¾ Channel - Determines the operating frequency to be used. It is not necessary to change the
wireless channel unless you notice interference problems with another nearby access point.
¾ Mode - This field determines the wireless mode which the device works on.
• 11b only - Only 802.11b wireless stations can connect to the device.
• 11g only - Only 802.11g wireless stations can connect to the device.
• 11n only - Only 802.11n wireless stations can connect to the device.
• 11bg mixed - Both 802.11b and 802.11g wireless stations can connect to the device.
• 11bgn mixed - All 802.11b, 802.11g and 802.11n wireless stations can connect to the
device.
¾
Channel Width - Determines the channel width to be used. It is unnecessary to change the
default value unless required.
¾
Max Tx Rate - Specifies the maximum transmit rate of the device through this field.
¾
Enable Wireless Radio - Select or deselect this check box to allow or deny wireless stations
to access the device.
