Page 13
XRD9829REF
13
Rev. 1.00
RL
VRT
VRB
VDD
VIN0
XRD9829
C
I
S
8-Bit Offset
DAC
Figure 9. Simplified Block Diagram Showing Fine Offset Adjustment by XRD9829
18. Switch the black target to the enclosed white target. From the CAPTURE menu select
SNAP SHOT for a single line scan of the white target. A typical result of a white
target is shown below.
