Side Burner Installation
Grill Assembly — 8200 Series
11
Fig. 12
4. Secure the rear of the shelf by inserting (1) self tapping screw in
the back of the grill and through the shelf tab (Fig. 16).
Fig. 13
Fig. 14
Fig. 16
Fig. 15
1. Position the side shelf hooks with the slots on the side of the
grill, near the back (Fig. 12 and 13).
2. Position the side shelf flange over the inside top edge of the grill
(Fig. 14). Push the side shelf downward to engage the hooks and
the flange at the same time, until the top surface is level with
the grill.
3. Secure the front of the shelf by inserting (2) self tapping screws
into the front flange underneath the shelf (Fig. 15).
