“THEBEN” Time Clock Setting Instructions continued…
Page 2 of 2 Document #1200368.doc Rev 4
01/17/07
· On Off ·
On
4. "HOUR" will be displayed across the top. Use the "◄" or "►" button to adjust the hour. Press "OK".
5. "MINUTE" will be displayed across the top. Use the "◄" or "►" button to adjust the minutes. Press "OK".
6. "MONDAY" will display. Select the days of the week that this particular program setting pertains to by using the "◄"
or "►" button until the first day of the cycle is flashing. Press "OK" and "COPY" will flash. Press "OK" and "ADD TU"
will appear. Continue to press "OK" to select the desired days. To bypass a day, press "►". After "ADD SU" is
displayed and/or selected, "STORE" flashes on the display. Press "OK". "NEW PROG" will flash across the display.
7. Press “OK” and "►" to set “TIME OFF” (control cycle). Repeat Steps 3­6 to program “TIME OFF” (control cycle).
8. Press “OK” to enter another program cycle or press “MENU” to return to the standard display.
C. VIEWING THE CHARGE (ON) AND CONTROL (OFF) CYCLES
1. To view the program settings, press the "Menu" until "Prog" starts flashing. Press "OK". "NEW PROG" will flash
across the top of the display. Press the "◄" or the "►" button until "CHECK" flashes on the display.
2. Continue to press and release "OK" button to review the programs.
D. CLEARING A SINGLE CHARGE (ON)/CONTROL (OFF) CYCLE
1. To clear individual program settings, press the "Menu" until "Prog" is flashing. Press "OK". "NEW PROG" will flash
on the display. Press the "◄" or the "►" button until "CLEAR" flashes on the display. Press "OK".
2. "SINGLE" will flash on the display. Press "OK" and use the "◄" or the "►" button until the day of the week desired is
displayed. Press "OK".
3. Use the "◄" or the "►" button to select "CLEAR" if clearing the current program setting. Press "OK" and the current
program setting will be cleared.
NOTE: If the setting to be cleared is not displayed, use the "◄" or the "►" button until "NEXT" is
displayed. Press "OK". The next program setting for the selected day will appear. Continue to
use the "NEXT" button until the desired program setting is displayed.
E. CLEARING ALL CHARGE (ON) AND CONTROL (OFF) CYCLES
1. To clear all existing program settings, press the "Menu" until "Prog" is flashing. Press "OK". "NEW PROG" will flash
on the display. Press the "◄" or the "►" button until "CLEAR" flashes on the display. Press "OK".
2. "SINGLE" will flash on the display. Use the "◄" or the "►" button until "ALL" is flashing on the display. Press "OK"
and "CONFIRM" will flash on the display.
3. Press "OK" to confirm the clearing of all program settings or press the "MENU" button to escape and not clear any
program settings.
F. OVERRIDES
1. To temporarily override a current charge or control cycle, press and release the "◄" and the "►" buttons at the same
time. "
" will appear and the clock will reverse the current program cycle. This override status will remain until
the next program cycle time, or it can be canceled by pressing and releasing the "◄" and the "►" buttons at the same
time again and "OFF" will display.
2. The time clock can also be placed in a permanent ON (Charge) or permanent OFF (Control) status. To do so, press
and hold both the "◄" and the "►" buttons until "PERM ON" ( ) or "PERM OFF" (
) is displayed.
Follow the same procedure to cancel the override.
G. RESET TIME
NOTE: The manufacturer recommends NOT using the "Res" button unless absolutely necessary.
1. Press the “Res” button to reset time, day, month, and year.
NOTE: This does not reset programmed control and charge cycles.
2. If the “Res” button is pushed, refer to the “Setting the Time Clock” instructions above for programming.
