Plug in firmly.
^ (d)
'OG?©£i?!
.ÙrÜlU/ÜJ:
cHSipi
Plug in firmly.
Back of speaker/battery-charger stand
If a gritty noise is heard, wipe away the dirt on the plug.
ifflSRffSJ ‘I'm”
Stf iSol Li'S ^o^
ENGLISH
□
This unit can correctly piay normal position
tapes. It can play high and metal position
tapes but is unable to take full advantage
of their characteristics.
B PLAY
O Insert tape. (The unit winds tape slack
and play is ready to start from the
fonward side @.)
Q Release hold.
Q Start play.
O Adjust the volume. (Set to 5-7 on the
main unit before adjusting on the
remote control.)
STOP; Press [ < ►/■].
■ CHANGE SIDES
During play
Press and hold ►/■].
Side playing (Refer to (b))
“F’: Forward side
"R”: Reverse side
■ FAST-FORWARD AND REWIND
While stopped
Forward: Press [FF].
Backward: Press [REW].
Press ►/■] to restart play.
■ TPS—Tape Program Sensor
Skip up to 9 tracks and start play from the
beginning of a track.
During play
Forward: Press [FF],
Backward: Press
[REW].
The number of skips increases each time
you do this.
To return to norma! play while using TPS,
press [◄ to restart play.
■ DOLBY B NR
Reduces noise on tapes recorded with
Dolby B NR to Vs,
During play
Press and hold [EQ]. (Refer to ©)
“□□NR”^“ ” (off)
Manufactured under license from _
Dolby Laboratories.
“Dolby” and the double-D symbol are
trademarks of Dolby Laboratories.
■ REVERSE MODE
(Refer to @)
“O”: Continuous play
“ Tape plays once only
While stopped
Press and hold [MODE].
■ QUICK SKIP
Skip about 10 seconds backward or
fonward.
During play
Press and hold [FF] or [REW].
■ TONE
During play
Press [EQ].
Each time you press the button (Refer to
©)
“S-XBS”: Boosts the bass
I Reduce volume if there is
i distortion
“TFIAIN”: Reduces noise that may
I disturb others
■ “ OH
S-XBS and TRAIN effects do not work
when using the speakers.
■ A-B REPEAT
Repeats play between two points.
(Refer to ®)
During play
1. Press [MODE] to specify A
(“B” flashes).
2, Press [MODE] to specify B.
The tape rewinds to point A and A-B
repeat starts.
Press ►/■I to restart play.
•This cancels if you press
[FF] or [REW],
•If you don’t specify point B, the unit
specifies it after 45 minutes or at the end
of the side.
•Normal play resumes aHer 50 repeats.
•The points may change slightly if there is
slack in the tape or you repeat a number
of limes.
•Do not use A-B repeat on tapes longer than
90 minutes.
0 USING THE SPEAKERS
Preparation:
insert the rechargeable battery (fully
charged) and connect the AC adaptor.
(The unit operates on the battery and the
speakers operate on AC power.)
Extend the speaker cord.
Insert a tape and put the unit into the
speaker/battery-charger stand.
Connect the speaker cord to the
remote control.
Switchfo
[ON], . .__
Operate the unit (^ above).
o
©
o
o
©
•The battery does not recharge during
play. Recharging starts again if play
stops (i.e., you stop play or the battery
goes flat).
•These speakers do not have magnetic
shielding. Do not place them near
televisions, personal computers, or other
devices easily influenced by magnetism.
Specifications
■ CASSETTE PLAYER
Track system:
4 track, 2 channel, stereo
Frequency range (Normal):
40-18000 Hz (-6dB)
■ GENERAL
-^tputjack: PHONES; 16 Q
Power output:
4 mW+4 mW (RMS,.,max.)
Power requirement:
Rechargeable battery; DC 1.2 V
(included rechargeable battery)
Battery; DC 1.5 V
(one R6/LR6, AA, UM-3 battery)
Dimensions (WxHXD):
108,8x75.0x19.0 mm
Mass: 160 g
(with rechargeable battery)
■ CHARGER
(SPEAKER/BATTERY-
CHARGER STAND)
Input: AC 220 V, 50 Hz, 25 mA
(for China) /
AC 220 V, 60 Hz, 30 mA
(for Korea)
Output: DC 1,2 V, 350 mA
Play lime:
[Approximate operating time in hours
(in hold mode, at 25 °C, on a flat,
stable surface).]
Battery type
Time
(unit: hour)
Rechargeable (A) 37
Alkaline 63
Both together (A) 100
(A) When the rechargeable battery
(included) is fully recharged
(requires 5 hours)
•Operating conditions may reduce the
operating times shown above.
Note
Specifications are subject to change
without notice.
Mass and dimensions are
approximate.
