38
English
FB275BT / FB275BTB
FM tuner
Frequency Range: 87.5 MHz to 107.9 MHz
Usable Sensitivity: 11 dBf
50 dB Quieting Sensitivity: 17 dBf
Alternate Channel Selectivity: 75 dB
Stereo Separation (1 kHz): 35 dB
Frequency Response (±3 dB): 30 Hz to 15 kHz
Audio
Maximum Power Output: 200 W (50 W X 4 ch)
Bass Control Action (100 Hz): ±14 dB
Treble Control Action (10 kHz): ±14 dB
Line Output (with A/C 1 kHz, 10 kΩ): 1.8 V
11. SPECIFICATIONS
SD player
System: Multimedia audio system
Frequency Response: 10 Hz to 20 kHz (±3 dB)
Dynamic Range: 80 dB (1 kHz)
Harmonic Distortion: 0.01%
Notes:
• Specifications comply with JEITA Standards.
• Specifications and design are subject to change
without notice for further improvement.
• Please make sure when connecting external power
amplifier, that you properly, to the car chassis,
ground the amplifier.
• If this is not done, severe damage to the source
unit may happen.
Power Output:
17 W RMS x 4 Channels at 4 Ω and ≤ 1%
THD+N
Signal to Noise Ratio:
87 dBA (reference: 1 W into 4Ω)
General
Power Supply Voltage:
12 V DC (10.8 V to 15.6 V allowable), negative
ground
Current Consumption: Less than 15 A
Speaker Impedance: 4 Ω (4 Ω to 8 Ω allowable)
Weight: 1.87 lb. (0.85 kg)
Dimensions:
178 mm Width X 50 mm Height X 154 mm
Depth
Bluetooth
®
wireless technology
Compliance: Bluetooth ® 1.2
Frequency Range: 2.40~2.4835 GHz, ISM band
RF Power: Class 2 (2.5mW)
Profiles: HFP, A2DP, AVRCP
Operating Temperature: -20ºC ~ 60ºC
Telephone Operation:
Noise reduction, Echo cancellation,
Full duplex telephony
Mic Input (External): 2.2k ohm, 2V electret
