The features you want.
The power you need.
Power Switch
Glows green when
AC power is present
at the power cord. Channel Indicators
For each channel, a column of LEDs
indicate a full range of amplifier diag-
nostics and information, including Fault,
Thermal, Ready, Clip, Signal Presence
and Signal Level. Intelligent LCD Screen and Controls
Lets you adjust the amplifier’s attenuation
and muting, configure the amp, recall DSP
presets, and set up and view error monitor-
ing. The presets allow you to quickly recon-
figure the amp for various applications. Indicators
Power, Data
and Bridge
Mode.
AC Mains
Circuit Breaker
Offers extra protection
for the amplifier. Analog Inputs Section
• Balanced Analog
XLR Inputs.
• Balanced Analog XLR
Daisy-chain Outputs.
• Input Ground Lift Switch.
Digital Inputs Section
• AES/EBU Digital Input
XLR Connector.
• Active Link/Out
Connector.
Networking Section
Accepts a connector from
a TCP/IQ network cable.
• LINK ACT indicator
shows network activity.
• 100 Mb indicator shows
a 100 Mb network
connection.
• Preset indicator blinks
to indicate active preset;
count flashes to
determine number.
• IQ Data LED shows
IQ link activity.
Outputs Section
• 4-Pole Speakon ®
Output Connectors:
Accept 2-pole or
4-pole Speakon
connectors.
• 5-Way Binding Post
Output Jacks: Accept
banana plugs, spade
lugs or bare wire.
Patented Class-I switching output • Highest output voltage available
Lightweight 2U package • Global regulated power supply
Power Factor Correction (PFC) • Studio-grade DSP inside
Direct digital audio inputs • 24-bit / 96-kHz converters
Integrated networking • Intuitive LCD display
Rugged chassis design
POWER OUTPUT
STEREO MONO
8 Ohm 4 Ohm 2 Ohm 8 Ohm 4 Ohm
I-T8000 2100 W 4000 W 3500 W 8000 W 7000 W
I-T6000 1500 W 3000 W 2500 W 6000 W 5000 W
I-T4000 1250 W 2000 W 1800 W 4000 W 3600 W
Guaranteed minimum power output per channel, 20Hz to 20 kHz, <0.35% true THD, both
channels driven. Rated power not part-tolerance dependent.
