MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS
FRONT PANEL
O
Power Switch [POWER ON/OFF]
Power is switched on to supply power to the Multiport
Hub when this switch is pressed to the ON position
(POWER Indicator lights), and is switched off when the
switch is pressed to the OFF position.
e Fuse [FUSE (POWER)]
Power fuse. Use a 125 V, 3.15 A fuse to replace it.
0
Power Indicator [POWER]
Lights red when POWER ON/OFF Switch O is pressed
to the ON position, and goes out when POWER
ON/OFF Switch O is pressed back to the OFF position.
-3-
