1
VoIP Loudspeaker Amplifier Operations Guide
930106D
CyberData Corporation
1 Product Overview
The Voice-over-IP (VoIP) Loudspeaker Amplifier (PoE) uses a single cable to connect to existing
LANs to broadcast digital audio over your public address system. The small footprint and low
height makes this an ideal loudspeaker amplifier to discreetly mount almost anywhere.
1.1 Typical System Installation
illustrates how the VoIP Loudspeaker Amplifier (PoE) is normally installed as part of a
public address system.
Figure 1. Public Address System—SIP
Generic PoE Hub
Server
VoIP Phone
1
2
3
4
5
6
VoIP Loudspeaker Amplifiers—PoE
