TV/VideO Button
- Press the TV/VIDEO button
to select desired input for Main Picture or PIP frame
(when the PIP is displayed).
Signal coming from;
REARVIDEO/AUDIOINPUT2TERMINALS
REAR VIDEO/ALIDIOINPUH
TERMINALS
TV or CABLE
Signal coming from:
REAR VIDEO/AUDIO INPUT 2 TERMINAL^
REAR VIDEO/AUDIO INPUTS
TERMINALS
TV or CABLE
PIP Frame
RGCSII Button
— Press the RECALL button to
review:
Q] Audio Mode status
E] CH number or Video Input selected
0] Sleep Timer status
g] Clock time
[5] Channel Caption (Station Identifier)
m
a
R-Tune Button
- Pressing the R-TUNE (RAPID
TUNE) button will switch between the last two channels
selected on the nurneric keypad. _ _
NOTE: When rapidly scanning channels with the
CHANNEL UP/DOWN button, pressing the
R-TUNE button will switch between the last
channel scanned, and initial channel at the start
of scanning.
CHANNEL NOW
BEING VIEWED
4
Press Button
Press Button Again
CHANNEL
PREVIOUSLY \REWEO
Multi Button
The MULTI button can be programmed to operate
up to six (6) Remote function buttons at the same
time.
For Example: TV Power/On, VCR Power/On and
Cable box Power/On (selected brands) can be operated
at the same time with one press of the MULTI button.
Procedure
1. First program the Remote for the selected device
Infrared access code. Confirm that the Remote
Control is compatible with the equipment.
2. Face the Remote Control transmitter away from all
equipment remote sensors.
3. Press and hold the Remote POWER button, then
press and hold the ACTION button down at the
same time for three seconds. (All previous
commands are erased.)
PRESS AT THE SAME TIME
FOR THREE SECONDS
4. After three seconds, let go of the POWER and
ACTION buttons.
5. Press the MULTI button.(Waiting more than 30
seconds without pressing another button will exit the
programming mode.)
6. Press a maximum of six (6) function buttons on the
Remote.
Each button you press is equal to one function. If six
(6) Remote button functions are entered, all will
register in the MULTI button memory in the
sequence entered. When finished, press the MULTI
button to end the program mode.
The following is an example flow chart of Remote
functions that can be programmed into the MULTI
button (The VCR Mode button should be
programmed before starting procedure see pg. 30).
PRESS ATTHE SAMETIME
FOR THREE SECONDS PRESS PRESS
PRESS PRESS PRESS TO END
PROGRAM MODE
Now you can turn the TV and VCR ON/OFF at the
same time with one press of the MULTI button.
To delete entered functions - Press and hold the
Remote POWER button then press and hold the
ACTION button down at the same time for three
seconds. Now you can enter from one to six different
Remote functions.
NOTE:
You can also program the MULTI button to perform
most individual Remote Control button functions.
Buttons which continuously perform a function as
long as press^ (Volume Up/Down, Channel
Up/Down, etc.) cannot be programmed. Only those
buttons which perform a function when initially
pressed (Power On/Off, Mute, Direct Channel
Entry, etc.) can be programmed.
- 1 5 -
