3 Menu functions Leica DISTO™ A8 1.1.0 gb
D
GB
F
I
E
P
NL
DK
S
N
FIN
J
CN
RC
ROK
PL
H
RUS
CZ
17 Double tilt measurement
18 Single Pythagorean measurement
19 Double Pythagorean measurement
20 Beep
21 Offset settings
22 Reference (tripod)
23 Continuous laser
Menu functions
Presettings
The menu allows selection of the settings that will
remain in memory after the instrument is switched
off.
Navigation in the Menu
Press the MENU -key {A, 14} repeatedly to scroll
through the possible menu functions.
When the desired menu option appears, select it with
the EQUAL - key {A, 5}, scroll through the possible
settings with the PLUS - key {A, 3} or the MINUS -
key {A, 11} and store the selected setting with the
EQUAL - key {A, 5}. Press CLEAR - key {A, 9} to leave
the menu without saving any changes in the settings.
Set unit of distance
"UNIT ?" and the DISTO symbol with the laser beam
{B, 1}.are displayed on the screen
Possible units:
Set unit of tilt
"UNIT ?" and the tilt symbol {B, 10} are displayed on
the screen.
Possible units:
Beep
The Beep symbol is displayed. It can be switched on
or off.
Distance Area Volume
0.000 m 0.000 m² 0.000 m³
0.00 m 0.00 m² 0.00 m³
0 mm 0.000 m² 0.000 m³
0.00 ft 0.00 ft² 0.00 ft³
0.00 1 /
32
ft in 0.00 ft² 0.00 ft³
0' 0''
1
/
32
0.00 ft² 0.00 ft³
0.0 in 0.00 ft² 0.00 ft³
0 1 /
32
in 0.00 ft² 0.00 ft³
±90.00°
±180.00°
360.00°
0.00%
0.0 mm/m
0.00 in/ft
