3.1 General definition
3.1.1 Characters
All characters of the ASCII- code smaller than 255 are permitted (see “Character set“ in the ap-
pendix) A command is ended with ASCII-code 13
command like
nator).
DISTO
TM
pro
4
/ DISTO
TM
pro
4
a, also send a terminator at the end of a response. It is the
code.
3.1.2 Input
Every command consists of one or more characters and a terminator.
Examples:
a
DSP 12345/F
Numerical input (parameters of a command, %) are always entered as integers (whole num-
bers). The following format is permitted:
Sign (optional) and numbers without leading zero: -8007.
3.1.3 Response
There are one or more responses to every command. The following responses are possible:
?
-
OK-prompt:.
DISTO
TM
pro
4
/ DISTO
TM
pro
4
a are ready to receive
new commands.
@E123
-
Error message: a three character code is displayed in accordance
with the table in the appendix.
12..10+12345678
- One or more data words with terminator
Plain text
-
Plain text information
Each command puts out either an OK-prompt or an error massage.
3.1.4 WI-data format
A data word as a response consists of 16 character. The following combinations are possible:
