Displaced
6 Writes „Online Disto“
Output:
?
or @Exxx
5.11 Read keypad (KEY)
Function:
Enables keypad to be read.
Input:
KEY %1
%1. Parameter x coordinate
<=0 Waits on key
>0
(max.
30000) Timeout [ms] to read key
Output:
WI5000
or @Exxx
5.12 End cover output (ENDCOVER)
Function:
Outputs end cover code
Input:
ENDCOVER
Output:
WI202
or @Exxx
Remarks: 3 = no magnet, 2 = one magnet at the left (swivel foot),1 = one magnet at the
right (alignment aid), 0 = two magnets
5.13 Output beep sound (BEEP)
Function:
Emits beep sound.
Input
BEEP %1
%: Beep length 0..5000 [ms]
Output:
?
or @Exxx
5.14 Delete all data (DELALLDATA)
Function:
Deletes all data sets!
Input:
DELALLDATA
Output:
?
or @Exxx
5.15 Read memory (GETDATA)
Function:
Reads data memory.
Input:
GETDATA %1 %2
%1. Parameter
n Starting range (n larger than, equal to 1)
%2. Parameter
n End range (n smaller than equal to 800)
Output:
WI11 WI31 or WI22 or WI314 or WI315 WI71 WI72 WI73
?
or @Exxx
Remarks : Every data set ends with a terminator.
From 1 to 800 data set can be transmitted.
After the last data set has been transmitted, a “?“ appears as confirmation of
the end of the function.
