Appendix
EFIS-D60 Installation Guide
5-19
Appendix F: Weights
Adding any new instrument to an aircraft requires the installer to be aware of its weight and how
that affects the overall weight and balance of the plane. The following are the weights of the
EFIS-D60 and associated Dynon-supplied sensors.
Installed EFIS-D60 .......................................................................................2 lb 13.5 oz (1.287 kg)
EFIS-D60 + Internal Backup Battery ................................................................3 lb 4 oz (1.465 kg)
EFIS 25-pin wiring harness ...................................................................................11.2 oz (0.32 kg)
EDC-D10A ............................................................................................................3.6 oz (0.102 kg)
EFIS OAT ................................................................................................................3.2 oz (0.08 kg)
Heated AOA/Pitot Probe & Heater Controller ......................................................11.2 oz (0.32 kg)
Unheated AOA/Pitot Probe......................................................................................5.6 oz (0.16 kg)
Appendix G: EFIS-D60 Specifications
Mechanical
6.95” wide x 4.90” tall x 4.51” deep (177 x 125 x 115 mm)
Operating
Temperature
-22° to 122° F (-30° to 50° C)
Power
Voltage:
10 - 30 Vdc
Power:
12 watts typical; 17 watts maximum
Connections
Wiring: DB25
male
connector
Screen
Type:
AMLCD, TFT (Thin Film Transistor)
Backlight: 800 nits
Size:
7.0” diagonal (178 mm)
Resolution: 854 x 480 color pixels
Inputs/Outputs
1 - AOA Audio Alarm
1 - RS-232 bidirectional PC communication and GPS aiding
input
1 - RS-232 serial encoder output
