Appendix
5-18
EFIS-D60
Installation
Guide
Appendix D: Replacing the EFIS-D60 Internal Backup Battery
1. Remove the two screws (either #1 Phillips or 7/64” hex, depending on when your unit
was manufactured) from the small, rectangular battery door on the side of the EFIS-D60.
Remove the battery door. Do not remove any other screws from the case of the unit.
2. If you previously had a battery, disconnect it from the EFIS-D60 by unplugging the
battery connector and gently pulling out old battery. It is safe to gently pull on the battery
wire to remove the battery.
3. Insert the new battery with the bumpy side up.
4. Connect the battery connector to the battery. The connector is keyed; make sure it is
positioned correctly.
5. Position the connector so it is centered on the end of the pack. Verify that the battery
pack will not interfere with insertion of either of the door screws.
6. Reinsert screws and tighten to 12 in-lbs.
Appendix E: Upgrading EFIS-D60 to EFIS-D100
The EFIS-D60 is Dynon’s simple, more affordable version of Dynon’s full-featured EFIS-D100.
Your EFIS-D60 can be upgraded to the feature set of the EFIS-D100, which provides the
following features and more:
• HSI Capability
• Optional autopilot interface
• GPS and NAV radio interconnectivity
• Interoperability with other Dynon instruments
• Checklists
• Bugs
• Timers
• On-screen information such as clock, VSI, OAT, G-meter
The upgrade process can only be done at the factory. Contact Dynon Customer Support
(
or 425-402-0433) for upgrade pricing, turnaround time, and other
details.
