EdgeAccess® Universal Chassis System
4.8 Trap Configuration
Traps are messages that require management attention and are routed to the Network Manager, but do
not trigger alarms. Use the Trap Configuration screen to view the current configuration and to enable
or disable traps for the 2340. See Figure 13 and Table 14. To configure traps, follow these steps:
1. From the System Configuration menu type 3, "Trap Configuration," and press .
2. At the Trap Configuration screen, type the number for a trap and press .
Note: "Master Trap Control" enables or disables all traps; the default is Disabled.
2. Press to cycle to Enabled or Disabled and press .
3. To return to the System Configuration menu, press .
------------------------TRAP CONFIGURATION--------------------------------
1) Master Trap Control Disabled
2) LOS/CLS Traps Enabled
3) SQL Traps Enabled
4) Redundancy Traps Enabled
5) Configuration Traps Enabled
6) Diagnostic Traps Enabled
7) Authentication Traps Enabled
8) Power/Fan Malfunction Traps Enabled
9) Cold Start Traps Enabled
10) Alarm Input Traps Enabled
11) Security Violation Traps Enabled
Figure 13. Trap Configuration Screen
Table 14. Trap Definitions
Type of Trap Definition
2) LOS/CLS Loss of Signal (electrical)/Composite Loss of Signal (optical); one
or both received signals fail
3) SQL Squelch (for received signal)
4) Redundancy Monitors redundant operation activity
5) Configuration Setup errors, including mismatches with other modems
6) Diagnostic Monitors loopback
7) Authentication Checks for SNMP access and read/write community string
8) Power/Fan Malfunction Power is low or fan is off
9) Cold Start
Monitors the reset function
10) Alarm Input UCS 1001 function; see the UCS 1001 User Manual
11) Security Violation Not used
Model 2340 User Manual 4-9
