Technical Specifications
Wavelengths
1310nm, 1470nm, 1490nm, 1510nm, 1530nm, 1550nm, 1570nm, 1590nm,
1610nm
Insertion Loss (End to End)
Model 6004
< 2.5dB
Model 6004 with 1310nm
<3dB for CWDM wavelengths
<1.5dB for 1310nm channel
Model 6008
<4.5dB
Model 6008 + 1310 wavelength
<5dB for CWDM wavelengths
<1.5dB for 1310nm channel
Optical Connectors
SC
Physical Dimensions
Model 6004
7.9"H x 1.0"W x 10.4"D (201 x 25 x 264mm)
Model 6008
7.9”H x 2.0W" x 10.4"D (201 x 50 x 264mm)
Weight
Model 6004
1.2 lbs. (0.54kg)
Model 6008
2.4 lbs. (1.08kg)
Operating Environment
Temperature
0° to 50°C
Humidity
Up to 95% (Noncondensing)
REGULATORY COMPLIANCE
UL60950/CSA C22.2 No. 60950
IEC 60950
IEC 60825-1
FCC Part 15 Class A, AS/NZS3548, CS-003
EN55022, EN55024
NEBS Level 3 Tested and Certified
