4. Troubleshooting
4.1 Test Accessories
The following test accessories will aid in troubleshooting the operation of the 2262
T1/E1 Fiber Optic Modem.
•
Plastic loopback rod (supplied with modem for non-laser applications)
•
Standard Data Test Set (not supplied with modem)
•
Photometer reading in dBm (not supplied with modem)
•
Short length of single mode fiber optic cable (not supplied with modem)
terminated with connectors compatible with those on the modem(s)
4.2 Diagnostic Procedures
4.2.1 Power Supply Diagnostic Procedure
Symptom
Step
Possible Cause
Remedy
Stand Alone only:
Power LED is off.
1
Power source, power
Return to factory for
supply.
repair.
Rack Mount only:
Power LED is off.
1
Power source, power
See 2201 Rack Chassis
supply.
User Manual for further
steps.
