Rev 2
KTA 970/KMH 980 Pilot’s Guide
006-18273-0000
TCAS I Controls and Displays
22
TCAS I Fault Annunciations:
Weather Only and Weather with TCAS I Mode
In the event of a failure, all TCAS I information will be removed from the
display. One of the following failure messages will be annunciated in the
upper left corner of the screen.
TEXT Color Description
TCAS (Yellow) TCAS I System Failure.
GP FAIL (Yellow) GC362A Failure.
Additional failure information will be available in the TCAS I ONLY mode,
if the failure will permit mode change.
TCAS I ONLY mode
In the event of a failure, all TCAS I information will be removed from the
display. If the failure will disallow mode change, the mode shall revert to
the Weather Only mode and the fault shall be displayed as above.
Otherwise, one or more of the following failure message will be annunci-
ated in yellow text.
TCAS SYSTEM FAIL TCAS PROCESSOR
UPPER ANTENNA LOWER ANTENNA
RADIO ALT #1 RADIO ALT #2
ATTITUDE HEADING
TRAFFIC DISPLAY #1 TRAFFIC DISPLAY #2
ALT DATA #1 & #2 GP RAM
NO RADAR 429 DATA NO TCAS 429 DATA
