Finding your way around:
There are ten types of pages that may be displayed on the right side of the screen.
Each has multiple page numbers:
AlliedSignal General Aviation Avionics
400 North Rogers Road
Olathe, Kansas 66062-1212
TELEX 669916 KINGRAD • FAX 913-791-1302
TELEPHONE (913) 768-3000
© 1995 AlliedSignal Inc.
5/95 006-08792-0000 2K Printed in USA
A
Airport (APT) Pages
1
Airport identifier, elevation, name, city,
state/province/country, use type (if
military or private-use)
2 Latitude/longitude, bearing/radial and
distance relative to present position
3 Runway numbers, length, surface, lighting
4 Airport communication frequencies
5 Airport remarks
VOR Pages
1
VOR identifier, frequency, name,
latitude/longitude
2 Magnetic station declination, bearing/
radial, distance relative to present position
NDB Pages
1
NDB identifier, frequency, name,
latitude/longitude
2 Bearing/radial and distance relative to
present position
Supplemental (SUP) Pages
0
Used to choose method of user-defined
waypoint creation
1 Latitude/Longitude, bearing/radial and
distance relative to present position
2 Reference waypoint (default is nearby
VOR), radial and distance from reference
3 User-defined waypoint remarks
Active Waypoint (ACT) Pages
Waypoint pages for the active waypoint
and the waypoints in FPL 0
Navigation (NAV) Pages
1
Active waypoint/leg, CDI/crosstrack
distance, desired track, actual track,
bearing, time to active waypoint
2 Present position (latitude/longitude or
radial/distance)
3 Present time, departure time, ETA at
destination, elapsed flight time
4 Moving map
Flight Plan (FPL) Pages
0
Active flight plan
1-9 Stored (numbered) flight plans
Calculator (CAL) Pages
1
Trip calculations for distance, bearing,
and ETE
2 Trip calculations for fuel requirements
3 Pressure altitude
4 Density altitude
5 True airspeed (TAS)
6 Winds aloft
Setup (SET) Pages
1
Position initialization for GPS receiver
2 Date, time, and time zone initialization
3 Data base update
4 Turn anticipation enable/disable
5 Default first waypoint character
6 Nearest airport criteria
7 SUA alert enable/disable
8 Baro set, indicated altitude, baro set units
Other (OTH) Pages
1
GPS receiver state, estimated position
error
2 GPS satellite signal status
3 List of user-defined waypoints
4 List of airports and user-defined
waypoints with stored remarks
5 Software versions, total hours of
operation, total power cycles
