NAV 4 (Moving Map) Page Tips
To change the map scale factor:
1. Press the
B
button. The cursor comes up over the map scale in the
lower left corner of the map display.
2. Use the right inner knob to change between scale factors (figure 3).
3. For terminal area operations select AUTO scale factor.
To change what information is displayed on the map:
1. Press the
B
button, select Menu? and press the
F
button to bring up a
pop-up menu (figure 4).
• Line 1: Display 5 nearest special use airspaces (SUAs), on or off
• Line 2: Display 9 nearest VORs; on or off
• Line 3: Display 9 nearest airports; on or off
• Line 4: Map orientation; N
↑
=North up, DTK
↑
=Desired track up, TK
↑
=
Actual track up (when groundspeed > 2 kts)
2. Use the right outer knob to select the desired item, and the right inner knob
to change the setting.
-3-
25.8nm
SGJ
{
>Leg
>117kt
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
100
KJAX
"SGJ
OMN
KCVN
%
%
%
%
Menu?
17.6nm
SGJ
{
>Leg
>117kt
APT VOR NDB SUP ACT NAV FPL CAL SET OTH
SUA:
off
VOR:off
APT:off
112°
KJAX
"
KORL
OMN
%
%
% %ORL
GJ
Figure 3
