Controls, Lcd display – Sangean H203D (V1) User Manual
Page 4
GB
Controls
Speaker
LCD display
Station preset
Power button
Info / Menu button
Band button
Select button
Tuning up / down button
Volume up / down button
Emergency buzzer
Torch button
Torch
Multi purpose handle
DC IN socket
FM wire antenna compartment
Battery compartment
Bracket holder
USB socket for software upgrade
LCD Display
F
H
M
L
E
A
B
C D
G
I J
K
N
O
P
Q
Sleep indicator
Egg timer indicator
AM / FM indicator
Clock digits
DAB indicator
FM indicator
Two line text display
G
F
E
D
C
B
A
5
7
5
4
0
9
4
6
8
8
7
6
