PoE Power/Video/Data UTP Transceiver User Manual
Specifications
Model
HXVB200T/T
A
HXVB200R/R
A
HXVB201T
HXVB300
T
HXVB300
R
HXVB301
T
HXVB301
R
HXVB305T
HXVB305R
HXVB408
R
HXVB604R
Signal
Channel
1ch video
(passive)
1ch power
1ch dat/audio
1ch video
(active)
1ch power
1ch data
1ch video
(active)
1ch power
1ch data
1ch video
1ch audio
(active)
1ch power
1ch video
(active)
1ch HPower
1ch data
8ch video
(passive)
8ch power
8ch data
4ch video
(active)
4ch power
4ch data
Video
Frequency response range:DC-6MHz ;Common/differential mode rejection:15KHz-6MHz 60dB typ.
Wire type
24AWG UTP CAT5 or higher; DC loop resistance≤18Ω/100m;Differential capacitance:62pF/m(max)
Impedance
UTP or RJ45:100Ω BNC COAX:75Ω
Power
Receiver input AC24-28V or DC30-38V(HXVB305R input DC56V);Transmitter output constant DC12V
Suppression
6kV 1.2×50uS;3kV 8×20uS
6KV 1.2uS×50uS;4KV 8uS×30uS
W / M
40g / 54*28*22.5mm
90g / 81*58*30mm | 120g
500g / 180*80*35mm
Environment
Temperature: (0~50℃) Humidity: (0%~95%)
Note: HXVB305 is high-power PoE transceiver use DC56V 1A input power; other transceiver is standard PoE transceiver, use AC28 or
