Page 9

ASSEMBLY OF THE KNUCKLE ARMS

Step 1

Step 2

Step 3

Assemble both right and left side.

36053

40520

36053

4mm

40528

36055

30656

4x4mm

34053

40527

4mm

40536

8x12x0.3mm

ew cr

emen

94034
4x4mm
Set Screw

.....x2

40218
8x12x0.3mm Washer

.....x2

94042
4mm
Nylon Nut

.....x4

40528
King Pin Screw

.....x4

40527
Knuckle Arm
Bushing

.....x4

36055
2.5x16.8mm Pin

.....x2

ASSEMBLY OF THE FRONT SUSPENSION ARMS

Step 1

Step 2

Assemble both right and left side.

Approx. 9.5mm

1•1

4x10mm

2.5mm

36020

36861

36850

36690

30657

36170

36870
4x10mm
Set Screw

.....x2

90020
2.5mm E-Ring

.....x4

36861
5x35mm
Turnbuckle

.....x2

36170
3x44.3mm Arm Shaft

.....x2

36850
7mm Ball

.....x2

ASSEMBLY OF THE FRONT SUSPENSION ARMS

Step 1

Step 2

Assemble both right and left side.

3x25

3mm

36640

36171

94008
3x25mm
Hex Screw

.....x2

94041
3mm Nylon Nut

.....x2

90021
3mm E-Ring

.....x8

36640
4x47mm Arm Shaft

.....x2

36171
4x74.1mm Arm Shaft

.....x2

Insert the front drive shaft into
cap joint before assembly.
